1.2V 600-10000mAh AA/AAA/C/D NiMh Industrial Battery

Short Description:

With 20 Years of Experience, Pkcell has become a leading Li-ion Battery Pack manufacturer, specializing in the production of the 18650 battery packs.


Nominal Voltage: 1.2V

Max Constant Charging Current (0.1C):60-1000mAh

Max Continuous Discharging Current (1C): 600-10000mAh

Cycle Life@25°C @0.2C: 500+

Self Discharge Rate: ≤3%/Month@25°C

Operating Temperature: -10~50 °C

Recommend Storage Temperature: 10~25 °C

ApplicationsDigital multimeters, Toys and RC transmitters, Medical devices, Remote controls


Certification

Certified By IEC, CE, MSDS, and More, Ensuring Top-Notch Quality and Safety.

Pkcell Certification


Product Detail

Product Tags

Key Features of Ni-MH Battery



  • 500+ Cycle Life
  • High safety
  • High Energy Density
  • Wide Discharging Temperature (-20~55℃)
  • Environmentally friendly
  • Comply with CE ROHS safety standard

Main Applications



  • Toys
  • Digital multimeters
  • RC transmitters
  • Medical devices
  • Remote controls
  • Electric toothbrush

Customizable Ni-MH Battery Packs

We build our custom packs using NI-MH batteries available in the following capacities: 600mAh, 700mAh, 800mAh,900mAh, 1200mAh, 1300mAh, 2000mAh, 2600mAh, 2800mAh, 3000mAh etc.

Battery is always available with different terminations, i.e., PC pins, solder tabs, leads, wire, cable, and connectors. We hope you find the one in our product list that suits you the best. If not, our Customer Service can assist you in finding one or offer custom-made terminations to meet your specifications.

We can achieve a wide spectrum of voltage and capacity options by combining these cells in various series (S) and parallel (P) configurations.

Here are some common nominal voltages and the typical capacity ranges achievable:

Nominal Voltage Series Config (S) Typical Parallel Config (P)
2.4V 2S 1P to 4P+
3.6V 3S 1P to 4P+
4.8V 4S 1P to 4P+
6V 5S 1P to 4P+
7.2V 6S 1P to 4P+
8.4V 7S 1P to 4P+
9.6V 8S 1P to 4P+
10.8V 9S 1P to 4P+
12V 10S 1P to 4P+
14.4V 12S 1P to 4P+
24V 20S 1P to 4P+

镍氢类目页(1)

Why Choose Pkcell Battery?

Decades Proven Expertise

20 years in battery manufacturing. Trusted by global brands and customers in 100+ countries.

Flexible Partnership

Flexible Formal Order MOQ (from $500) and samples available. Partnering with you from design to delivery.

Certified Quality

Strict QC in our 28,000 ㎡ facilityIEC, CE, RoHS certified for reliable performance.

Custom Solutions

50+ R&D experts design tailored battery packs and solutions for your unique needs.

FAQ

How long will my order take, how can I pay, and what are the shipping options?



  • Lead Time:  Standard samples typically arrive in 20-25 days. Formal orders usually take around 20-25 days
  • Payment Methods:  We accept various payment types, including T/T (Telegraphic Transfer), L/C (Letter of Credit), and PayPal.
  • Shipping:  We offer flexibility! Depending on your needs and location, we can ship your order via air freight (using carriers like FEDEX, DHL, UPS, EMS, etc.) or via sea freight.
  • Delivery Terms:  We can work with several common international shipping terms, including EXW, FCA, FOB, CFR, and DDU.



What is your minimum order quantity (MOQ), and can I get samples first?

We have a minimum order value of USD $500. The actual quantity you receive depends on the unit price of the specific batteries you choose. Absolutely! We understand you need to test our products. We're happy to provide samples for your evaluation before you place a formal order.

Can your battery packs meet requirements for special environments (like extreme temperatures, water/shock resistance)

Yes, absolutely. We can design and build battery packs tailored for challenging conditions. We offer solutions using 18650 cells rated for wide operating temperatures (e.g., discharge from -40℃ up to +85℃ discharge with specific cell types), and our pack designs can incorporate features for waterproofing, shock resistance, and intrinsic safety (explosion protection) as required by your application.

Do you provide certification services like UN38.3, CE, or UL?

Yes, we can facilitate and provide these certification services for your battery packs. The typical estimated lead times are:

  • UN38.3: Approx. 2 weeks
  • CE: Approx. 1 week
  • UL:  Approx. 5 weeks(Please note these are estimates and can vary based on testing queues and specific requirements.)
Do I Really Need a BMS for Nickel Metal Hydride Battery Pack?

No, you do not. However, NiMH battery packs are amongst the hardest batteries to charge accurately and because the BMS solutions are very cost effective we recommend having one in your design. The charging for NiMH batteries is based on forcing current through the battery whereas with lithium ion and lead acid batteries you can control overcharge by just setting a maximum charge voltage. Therefore, having an electronic safety in place will increase the overall life of the battery.

Ni-MH A/AA/AAA/C/D/ Specifications

Model Size Weight Voltage Capacity Action
A
49.5*16.7mm 27.6g 1.2v 1800mAh Request Quote Download
A
49.5*16.7mm 28g 1.2v 2100mAh Request Quote Download
A
49.5*16.7mm 29g 1.2v 2300mAh Request Quote Download
A
49.5*16.7mm 30g 1.2v 2500mAh Request Quote Download
AA
49.6*14.2mm 30 1.2v 600mAh Request Quote Download
AA
49.6*14.2mm 32 1.2v 700mAh Request Quote Download
AA
49.6*14.2mm 32 1.2v 800mAh Request Quote Download
AA
49.6*14.2mm 33 1.2v 900mAh Request Quote Download
AA
49.6*14.2mm 34 1.2v 1000mAh Request Quote Download
AA
49.6*14.2mm 35 1.2v 1100mAh Request Quote Download
AA
49.6*14.2mm 35 1.2v 1200mAh Request Quote Download
AA
49.6*14.2mm 36 1.2v 1300mAh Request Quote Download
AA
49.6*14.2mm 36 1.2v 1300mAh Request Quote Download
AA
49.6*14.2mm 36 1.2v 1400mAh Request Quote Download
AA
49.6*14.2mm 36 1.2v 1500mAh Request Quote Download
AA
49.6*14.2mm 36 1.2v 1600mAh Request Quote Download
AA
49.6*14.2mm 36 1.2v 1700mAh Request Quote Download
AA
49.6*14.2mm 36 1.2v 1800mAh Request Quote Download
AA
49.6*14.2mm 36 1.2v 1900mAh Request Quote Download
AA
49.6*14.2mm 36 1.2v 2000mAh Request Quote Download
AA
49.6*14.2mm 36 1.2v 2100mAh Request Quote Download
AA
49.6*14.2mm 36 1.2v 2200mAh Request Quote Download
AA
49.6*14.2mm 36 1.2v 2300mAh Request Quote Download
AA
49.6*14.2mm 36 1.2v 2400mAh Request Quote Download
AA
49.6*14.2mm 36 1.2v 2500mAh Request Quote Download
AA
49.6*14.2mm 36 1.2v 2600mAh Request Quote Download
AA
49.6*14.2mm 36 1.2v 2700mAh Request Quote Download
AA
49.6*14.2mm 36 1.2v 2800mAh Request Quote Download
AAA
49.6*14.2mm 36 1.2v 1300mAh Request Quote Download
AAA
49.6*14.2mm 36 1.2v 400mAh Request Quote Download
2-3AA
49.6*14.2mm 36 1.2v 650mAh Request Quote Download
AAA
49.6*14.2mm 36 1.2v 900mAh Request Quote Download
AAA
49.6*14.2mm 36 1.2v 800mAh Request Quote Download
AAA
49.6*14.2mm 36 1.2v 700mAh Request Quote Download
AAA
49.6*14.2mm 36 1.2v 1000mAh Request Quote Download
AAA
49.6*14.2mm 36 1.2v 600mAh Request Quote Download
AAA
49.6*14.2mm 36 1.2v 500mAh Request Quote Download
AAA
49.6*14.2mm 36 1.2v 400mAh Request Quote Download
AAA
49.6*14.2mm 36 1.2v 1200mAh Request Quote Download
AAA
49.6*14.2mm 36 1.2v 1100mAh Request Quote Download
C
49.6*14.2mm 36 1.2v 5000mAh Request Quote Download
C
49.6*14.2mm 36 1.2v 4500mAh Request Quote Download
C
49.6*14.2mm 36 1.2v 4000mAh Request Quote Download
C
49.6*14.2mm 36 1.2v 3500mAh Request Quote Download
C
49.6*14.2mm 36 1.2v 3000mAh Request Quote Download
SC
49.6*14.2mm 36 1.2v 3500mAh Request Quote Download
SC
49.6*14.2mm 36 1.2v 2500mAh Request Quote Download
D
49.6*14.2mm 38 1.2v 4000mAh Request Quote Download
D
49.6*14.2mm 38 1.2v 5000mAh Request Quote Download
D
61*32.2mm 38 1.2v 7000mAh Request Quote Download
D
61*32.2mm 38 1.2v 8000mAh Request Quote Download
D
61*32.2mm 38 1.2v 9000mAh Request Quote Download
D
61*32.2mm 38 1.2v 10000mAh Request Quote Download
