ICR18650 11.1V 4400-10000mAh Rechargeable Lithium Battery with PCM and Connector OEM/ODM

Short Description:

Rapid Quotes | Global Delivery | Get Solution in 1 business day | IEC62133, CE, UN38.3, RoHS, REACH 18650 11.1V 4400-10000mAh Rechargeable Lithium Battery Pack is safe to use, environmentally friendly and have long battery life. It comes with high energy density and provides excellent continuous power sources to your device. It should be used with a protection circuit board that guards the battery against over-charge, and over-discharge of the pack, and avoids over-current drawn.


Product Detail

Product Tags

Specification
Model    No ICR18650
Nominal capacity Customized
Nominal voltage 11.1V
Charging cut-off voltage 16.8V
Discharge cut-off voltage 11.0V
Dimension 18*54*65mm or customized
Weight 147g
Cycle life 500-1000 times
Standard discharge current 0.5C
Max continuous discharging current 2.0C
Temperature range Charge:0ºC~45ºC;32oF~113oF
Discharge:-20ºC~60ºC;-4oF~149oF
Storage:-20ºC~45ºC;-4oF~113oF
Key Features
1.High energy density.
2.Long cycle life,more than 500 cycles.
3.Environmental Friendly Chemistry
4.High Rate Charge/Discharge
5.No memory effects
5.High-output and high-load characteristics
6.Low self-discharge rate: under 3% self-discharge for one year
7.Comply with IEC62133 CB CE safety standard
8.Safe to ship : MSDS, UN38.3 cert. available
Application:
power tools,flashlight, medical device,self-balancing scooter,power bank,electric motorcycle,E-cigarette and so on

CONTACT US for more information and customized solutions







Model Size Weight Voltage Capacity Action
18650
18650
36*20*65mm 92.5g 3.7v 4400mAh Request Quote Download
18650
18650
20.5×38×68.5mm 102g 3.7v 6700mAh Request Quote Download
18650
18650
20.5×57×69.5mm 148g 3.7v 10050mAh Request Quote Download
18650
18650
20.5×75×69.5mm 200g 3.7v 13400mAh Request Quote Download
18650
18650
22×38×69mm 46g 7.4v 2600mAh Request Quote Download
18650
18650
19.5×69×76mm 95g 7.4v 5200mAh Request Quote Download
18650
18650
38.5×38×69mm 146g 11.1v 2600mAh Request Quote Download
18650
18650
38.5×38×134mm 425g 11.1v 6700mAh Request Quote Download
18650-6S6P
18650-6S6P
38×40.5×201mm 540g 22.2v 6600mAh Request Quote Download
