PKCELL 26650 3.2V 3500mah Cylindrical LiFePO4 Battery Cell

Short Description:

PKCELL IFR26650-3500 lifepo4 battery cell is with 26*65mm dimension, 3.2V 3500mah capacity, this is a capacity model with 3500mah along with the development of technology, which is common used in flashlights, battery packs.


Product Detail

FAQ

Product Tags

PKCELL IFR26650-3500 lifepo4 battery cell is with 26*65mm dimension, 3.2V 3500mah capacity, this is a capacity model with 3500mah along with the development of technology, which is common used in flashlights, battery packs.

Features

Sturdy and pressure resistant steel envelope

High capacity

Excellent cycle life

Excellent high and low temperature performance

Steady output voltage

Low self-discharge

Double safety protection

With outstanding high level of vibrations and shocks
Applications

Energy storage, Electric two-wheeled vehicle, three-wheeled vehicle, four-wheeled low-speed vehicle, UPS.
Individual cells should be integrated in specific battery pack according to the demands.The battery pack together with electronic system provides performance, thermal and safety management.

Specification

Item Rating Note
Model IFR26650-3500 26*65mm
Nominal Capacity 3500mAh Standard discharge, 0.2Cdischarge, 2.0V cut-off
Nominal Voltage 3.20V
Standard Charge Current 0.2C 0.2C, 3.65V (CC-CV)0.03C cut off.
Standard Discharge Current 0.2C 0.2C, 2.0V cut off.
Maximum Discharge Current 1750mA 0.5C, Continuous Current
  7000mA 2C , Peak Current
Weight 85g
Operating Temperature 0~45℃ Charge
  -20~60℃ Discharge
Storage Temperature -20~45℃ 1month
  -20~35℃ 3month
  -20~20℃ 1year
Application flashlights, power supplies, wireless data transmitters, electric thermal clothing, shoes, portable instruments, portable lighting equipment, portable printers, industrial instruments, medical instruments, vehicles etc.
