3.2V 3000mAh IFR21700 Li-FePo4 Battery
Short Description:
With 20 Years of Experience, Pkcell has become a leading Li-ion Battery Pack manufacturer, specializing in the production of the 18650 battery packs.
Nominal Voltage: 3.2V
Max Constant Charging Current (1C): 3000mA
Max Continuous Discharging Current (1.5C): 4500mA
Cycle Life@25°C@1C: 2000+
Self Discharge Rate: ≤3%/Month@25°C
Operating Temperature: -20~60 °C
Recommend Storage Temperature: -20~25 °C
Applications: Consumer Electronics, Energy Storage Systems, Industrial Equipment, Electric Vehicles
Certification
Certified By IEC, CE, MSDS, and More, Ensuring Top-Notch Quality and Safety.
PKCELL IFR26650 3.2 v 3400mah lifepo4 battery which is common used in flashlights, battery packs. Large scale production makes the IFR26650 3.2 v 3400mah lifepo4 battery cell become the most cost-effective cell in all lithium iron phosphate cylindrical cells in the world. LFP 26650 3.2V 3400mAh, Maximum 1C charge and 3C discharge, more than 2000 life cycle at 1C charge&discharge and 100% DOD.Features
Features
Sturdy and pressure resistant steel envelope
High capacity
Excellent cycle life
Excellent high and low temperature performance
Steady output voltage
Low self-discharge
Double safety protection
With outstanding high level of vibrations and shocks
Applications
Energy storage, Electric two-wheeled vehicle, three-wheeled vehicle, four-wheeled low-speed vehicle, UPS.
Individual cells should be integrated in specific battery pack according to the demands.The battery pack together with electronic system provides performance, thermal and safety management.
Specification
| Specification of 26650 lifepo4 3.2v 3400mah | |
| Size | 26*65mm |
| Charge voltage | 3.65V |
| Nominal voltage | 3.2V |
| Nominal capacity | 3400mAh |
| Cell Weight | Approx:87g |
| Charge current | Standard Charging::0.5C 1700mA |
| Rapid charge:1.0C 3400mA | |
| Standard Charging method | 0.5C CC(constant current)charge to 3.65V,then CV(constant voltage 3.65V)charge till charge current decline to≤0.05C |
| Charging time | Standard Charging:3.0hours(Ref.) |
| Rapid charge:2hours(Ref.) | |
| Max.charge current | 1C(3400mA) |
| Max.discharge current | 2C(6800mA) |
| Discharge cut-off voltage | 2.5V |
| Cycle Life | >1000cycles |
| Operating temperature | Charging:0℃~45℃ |
| Discharging:-20℃~60℃ | |
| Storage temperature | -10℃~ +60℃ |
| Warranty | 12 months |
