Li-ion Button Cell


Li-ion Button Cell Battery
Li-ion Button Cell/ Coin battery have different model available, are widely used to the wearable electronic devices and Bluetooth headset. We are professional lithium battery manufacturer, and we can provide customer power solutions.

Key Features:
1. High Operating Voltage (3.6V)
2. High energy density of up to 270WH/Kg
3. Non-magnetic stainless-steel case, hermetically sealed
4.Wide operating temperature range: Charge at 0~45℃ Discharge at –20~60℃
5. No leakage problem

Application:
PDA and IC cards, electronic clocks and watches, wearable electronic devices, tracking units, monitoring units, remote control keys, digital cameras, bluetooth headset battery, RC toys.

Customized Design:
Customized design battery pack is available, below Cell model list is only for reference, CONTACT US for detailed information and customized solutions.

Model

Nominal Voltage (V)

Nominal Capacity(mAh)

Continuous recommended current(mA) Recommended pulse current(mA) Diameter(mm) Height(mm)

Approx. Weight (g)

LIR1050 3.6 27±4 5.4mA 27mA 10.5 5 1.16
LIR1220 3.6 7±1 1.4mA 7mA 12.5 2 0.82
LIR1248 3.6 45±1 9mA 45mA 12.5 4.8 1.68
LIR1255 3.6 60±1 12mA 60mA 12.5 5.5 2
LIR1448 3.6 65±1 13mA 65mA 14.5 4.8 2.2
LIR1455 3.6 80±5 16mA 80mA 14.5 5.5 2.6
LIR1620 3.6 15±2 3mA 15mA 16 2 1.35
LIR1632 3.6 25±2 7.5mA 25mA 16 3.2 1.75
LIR1655 3.6 110±2 22mA 110mA 16 5.5 3.35
LIR2016 3.6 15±2 3mA 15mA 20 1.6 1.8
LIR2025 3.6 30±2 6mA 30mA 20 2.5 2.5
LIR2032 3.6 45±5 9mA 45mA 20 3.2 2.6
LIR2430 3.6 95±5 19mA 95mA 24.5 3 4.2
LIR2440 3.6 145±5 29mA 145mA 24.5 4 5.6
LIR2450 3.6 120±10 24mA 120mA 24.5 5 5.3
LIR2470 3.6 200±5 40mA 200mA 24.5 7.7 7.5
LIR3023 3.6 180±1 36mA 180mA 30 3.2 7.1
LIR3048 3.6 280±1 56mA 280mA 30 4.8 9.4

Bluetooth Headset Model

Model Nominal Voltage (V) Capacity(mAh) Continuous recommended current(mA) Recommended pulse current Diameter (mm) Height (mm) Weight Approx (g)
LIR1255 3.6 55±5 22mA 110mA 12.5 5.5+0.35 1.85
LIR1655 3.6 100±10 22mA 110mA 16.1 5.5+0.35 3
