PKCELL 18650 3.7V 8000-20000mAh Rechargeable Lithium Battery Pack

Short Description:

Li-ion Rechargeable Battery Pack
Cells can stay in storage for 12 months without requiring maintenance. The expected cycle life of a Li-ion in an application is about 1000+ cycles.)

Samples are available without custom made | Rapid Quotes | Global Delivery | Get Solution in 1 business day | IEC62133, CE, UN38.3, RoHS, REACH

Lithium Battery is known as the battery industrial over for quality, safety, price, and lead time. Our 18650 lithium battery pack shows real rated capacity at the price every company can accept. The protection circuit can be built-in for safety control include over-charging, over-discharge, short-circuit, and temperature control. The additional connector made by JST, Molex & Hirose is also available with a custom length of wires.


Product Detail

FAQ

Product Tags

Key Features
1. High Operating Voltage (3.7V)
2. High energy density, Advanced technology provides ultra-high capacity Li-ion batteries
3.Wide operating temperature range Charge at 0~45℃
Discharge at –20~60℃
4. Designed for a safe operation, all batteries are equipped with multiple safety features, including a safe shut-down separator and a safety vent
5. High-output and high-load characteristics; Max Continuous discharge rate is at 1.5C
6. Low self-discharge rate under 3% self-discharge for one year
7. long cycle life over 1000 times
8. No memory effects
9. Comply with IEC62133 CB CE safety standard
10.Safe to ship MSDS, UN38.3 cert. available

Application
GPS, GSM modem, Bluetooth Keyboard, Auto electronics, Toys, Barcode scanner,Tax Machine, Portable device, Light, Tracking system, Cash Machine, POS Terminal, Mine Equipment ,Alarms and security systems, Power bank, E- cigarette, Medical device, Electric bike, Electric scooter,etc

Customized Design:
Customized design battery pack is available, below Cell model list is only for reference, CONTACT US for detailed information and customized solutions.

Model Nominal Voltage(V) Dimension Capacity(mAh) Discharge Performance
Diameter(mm) Height(mm)
ICR10150 3.7 10.3 15 80 0.5C-1C
ICR10440 3.7 10.3 44 350 0.5C-1C
ICR10840 3.7 10.3 84 600 0.5C-1C
ICR14200 3.7 14.2 20 150 0.5C-1C
ICR14280 3.7 14.2 28 320 0.5C-1C
ICR14430 3.7 14.2 43 550 0.5C-1C
ICR14430 3.7 14.2 43 600 0.5C-1C
ICR14430 3.7 14.2 43 650 0.5C-1C
ICR14500 3.7 14.2 50.2 500 0.5C-1C
ICR14500 3.7 14.2 50.2 600 0.5C-1C
ICR14500 3.7 14.2 50.2 650 0.5C-1C
ICR14500 3.7 14.2 50.2 700 0.5C-1C
ICR14500 3.7 14.2 50.2 800 0.5C-1C
ICR14650 3.7 14.2 65 1000 0.5C-1C
ICR14650 3.7 14.2 65 1200 0.5C-1C
ICR16340 3.7 16.8 34 700 0.5C-1C
ICR16500 3.7 16.8 50.2 1000 0.5C-1C
ICR16500 3.7 16.8 50.2 1200 0.5C-1C
ICR16650 3.7 16.3 65.2 1800 0.5C-1C
ICR18350 3.7 18.3 35.2 850 0.5C-1C
ICR18500 3.7 18.3 50.2 1200 0.5C-1C
ICR18500 3.7 18.3 50.2 1400 0.5C-1C
ICR18500 3.7 18.3 50.2 1500 0.5C-1C
ICR18500 3.7 18.3 50.2 1600 0.5C-1C
ICR18500 3.7 18.3 50.2 1900 0.5C-1C
ICR18620 3.7 18.5 62.2 2000 0.5C-1C
ICR18650 3.7 18.5 65.2 1300 0.5C-1C
ICR18650 3.7 18.5 65.2 1500 0.5C-1C
ICR18650 3.7 18.5 65.2 1800 0.5C-1C
ICR18650 3.7 18.5 65.2 2000 0.5C-1C
ICR18650 3.7 18.5 65.2 2200 0.5C-1C
ICR18650 3.7 18.5 65.2 2400 0.5C-1C
ICR18650 3.7 18.5 65.2 2500 0.5C-1C
ICR18650 3.7 18.5 65.2 2600 0.5C-1C
ICR18650 3.7 18.5 65.2 3000 0.5C-1C
ICR18650 3.7 18.5 65.2 3350 0.5C-1C
ICR21700 3.7 21.5 70.2 4200 0.5C-1C
ICR22430 3.7 21.5 43.2 2000 0.5C-1C
ICR22500 3.7 22.3 50.2 2400 0.5C-1C
ICR22650 3.7 22.3 65.2 3000 0.5C-1C
ICR26350 3.7 26.5 35.2 2000 0.5C-1C
ICR26500 3.7 26.3 50.2 3200 0.5C-1C
ICR26650 3.7 26.3 65.2 4500 0.5C-1C
ICR26650 3.7 26.3 65.2 5000 0.5C-1C
ICR32550 3.7 32.5 55.2 5000 0.5C-1C
ICR32600 3.7 32.5 60.5 5500 0.5C-1C
ICR32650 3.7 32.3 65.2 6500 0.5C-1C
ICR34600 3.7 34.3 60.2 7000 0.5C-1C
