Ni-CD Button Cell

Model Normal Voltage (V) Capacity (mAh) Dimension Standard Charge Trikle Charge Current (mA) Weigh(g) Voltage for battery pack
Dia.(mm) Ht.(mm) Current (mA) Time (h)
B60K 1.2 60 15.3 6.1 6 14 2.0 3.2 3.6V
B100K 1.2 100 15.3 7.7 10 14 3.0 4.0 3.6V
B120K 1.2 120 23.4*15.1 5.2 12 14 4.0 5.3 3.6V
B170K 1.2 170 25.0 7.3 17 14 5.0 8.6 3.6V
B280K 1.2 280 25.0 8.4 28 14 8.0 12.0 3.6V
B9V120 9V 120 26*17 49.0 12 14 4.0 35.0 3.6V
