Li-ion Battery Pack


Li-ion Rechargeable Battery Pack
Cells can stay in storage for 12 months without requiring maintenance. The expected cycle life of a Li-ion in an application is about 500+ cycles.)

Key Features
1. High Operating Voltage (3.7V)
2. High energy density, Advanced technology provides ultra-high capacity Li-ion batteries
3.Wide operating temperature range Charge at 0~45℃
Discharge at –20~60℃
4. Designed for a safe operation, all batteries are equipped with multiple safety features, including a safe shut-down separator and a safety vent
5. High-output and high-load characteristics; Max Continuous discharge rate is at 1.5C
6. Low self-discharge rate under 3% self-discharge for one year
7. long cycle life over 500 times
8. No memory effects
9. Comply with IEC62133 CB CE safety standard
10.Safe to ship MSDS, UN38.3 cert. available

Application
GPS, GSM modem, Bluetooth Keyboard, Auto electronics, Toys, Barcode scanner,Tax Machine, Portable device, Light, Tracking system, Cash Machine, POS Terminal, Mine Equipment ,Alarms and security systems, Power bank, E- cigarette, Medical device, Electric bike, Electric scooter,etc
Model Nominal Voltage(V) Dimension Capacity(mAh) Discharge Performance
Diameter(mm) Height(mm)
ICR10150 3.7 10.3 15 80 0.5C-1C
ICR10440 3.7 10.3 44 320 0.5C-1C
ICR10840 3.7 10.3 84 600 0.5C-1C
ICR14200 3.7 14.2 20 150 0.5C-1C
ICR14280 3.7 14.2 28 320 0.5C-1C
ICR14430 3.7 14.2 43 550 0.5C-1C
ICR14430 3.7 14.2 43 600 0.5C-1C
ICR14430 3.7 14.2 43 650 0.5C-1C
ICR14500 3.7 14.2 50.2 500 0.5C-1C
ICR14500 3.7 14.2 50.2 600 0.5C-1C
ICR14500 3.7 14.2 50.2 650 0.5C-1C
ICR14500 3.7 14.2 50.2 700 0.5C-1C
ICR14500 3.7 14.2 50.2 800 0.5C-1C
ICR14650 3.7 14.2 65 1000 0.5C-1C
ICR14650 3.7 14.2 65 1200 0.5C-1C
ICR16340 3.7 16.8 34 700 0.5C-1C
ICR16500 3.7 16.8 50.2 1000 0.5C-1C
ICR16500 3.7 16.8 50.2 1200 0.5C-1C
ICR16650 3.7 16.3 65.2 1800 0.5C-1C
ICR18350 3.7 18.3 35.2 850 0.5C-1C
ICR18500 3.7 18.3 50.2 1200 0.5C-1C
ICR18500 3.7 18.3 50.2 1400 0.5C-1C
ICR18500 3.7 18.3 50.2 1500 0.5C-1C
ICR18500 3.7 18.3 50.2 1600 0.5C-1C
ICR18500 3.7 18.3 50.2 1900 0.5C-1C
ICR18620 3.7 18.5 62.2 2000 0.5C-1C
ICR18650 3.7 18.5 65.2 1300 0.5C-1C
ICR18650 3.7 18.5 65.2 1500 0.5C-1C
ICR18650 3.7 18.5 65.2 1800 0.5C-1C
ICR18650 3.7 18.5 65.2 2000 0.5C-1C
ICR18650 3.7 18.5 65.2 2200 0.5C-1C
ICR18650 3.7 18.5 65.2 2400 0.5C-1C
ICR18650 3.7 18.5 65.2 2500 0.5C-1C
ICR18650 3.7 18.5 65.2 2600 0.5C-1C
ICR18650 3.7 18.5 65.2 3000 0.5C-1C
ICR18650 3.7 18.5 65.2 3350 0.5C-1C
ICR21700 3.7 21.5 70.2 4200 0.5C-1C
ICR22430 3.7 21.5 43.2 2000 0.5C-1C
ICR22500 3.7 22.3 50.2 2400 0.5C-1C
ICR22650 3.7 22.3 65.2 3000 0.5C-1C
ICR26350 3.7 26.5 35.2 2000 0.5C-1C
ICR26500 3.7 26.3 50.2 3200 0.5C-1C
ICR26650 3.7 26.3 65.2 4500 0.5C-1C
ICR26650 3.7 26.3 65.2 5000 0.5C-1C
ICR32550 3.7 32.5 55.2 5000 0.5C-1C
ICR32600 3.7 32.5 60.5 5500 0.5C-1C
ICR32650 3.7 32.3 65.2 6500 0.5C-1C
ICR34600 3.7 34.3 60.2 7000 0.5C-1C
